Features:
1. Long distance APP remote control
2. Support almost every kind of one-wire or two-wires LED driver IC ;
3. Support setting pixel number and segment number, support up to 960 pixels;
4. With 18 kinds of LED strip music effects, 30 kinds of LED matrix music effects
and 180 kinds of non-music effects;
5. DC5V~24V wide range working voltage, reverse power supply input protection;
6. User setting saving;
Origin: CN(Origin)
Model Number: SP107E
Remote Distance: 10m
Item Type: RGB Controler
Material: plastic
Warranty: 1 year
Certification: ce
Certification: ROHS
Connection Mode: via-Bluetooth, terminal
Power Source: DC
Controled Method: APP
Features: music rhythm control
Wattage: 2w
Applicable Lights: SPI addressable light
Oscillation frequency: NULL
Max. Load Power: 960pixel
Voltage: 5-24V
APP name: LED Chord
system support: Android, IOS
built-in music mode (strip mode): 18 modes
built-in music mode (screen mode): 30 modes
built-in non-music mode: 180 modes
setting memory: yes
RGB light order adjust: yes
built-in Mic: yes
AUX input: yes
size: 85x45x22 mm
weight: 40g
Audio Input:
There are two ways to input the audio signal on SP107E, AUX IN and Build-IN
microphone:
AUX IN: Plug the supplied audio split cable into the “AUX IN” jack, connect the audio output source(MP3,Phone or tablet…)
and the speaker(or headset), controller will automatically switch into AUX input mode;
MIC: Disconnect the audio cable, controller will automatically switch into microphone input mode.
compatible with almost single wire & dual wire SPI IC:
Easy conenction:
package including:
APP screen surface:
CE and RoHS approved
