Description
Highlight
"1. Android 9.0 TV BOX+DVB-S/S2/S2X,DVB+T/T2/Cable/ATSC-C(J.83B)/ISDBT, AVS+
HEVC main 10 profile(10bit)，AUTO BISS，T2MI，GTFeeds，YUV422，Gtshare"
2.Amlogic S905X3 2GBRAM +16GBROM
3.Support 4K ultra-high definition display and decoder, Dual-core MIPS75Kf processors;
4. Support Uniable, DiSEqC1.0/1.1/1.2/USALS Mo fully support;
5.Support Full PowerVu, DRE &Biss key; AUTO BISS
6.Built-in Wifi 2.4G/5G+BT4.1, 802.1.1b/g/n/ac
"7.System is GT UI, GTStore Addons pre-installed.
Support SAT2 IP, GTshare APP"
8.Support 1PTV on GTPlayer,
9.Support CAM, NEWAM, MGAM, and CA card decoding;
ButtonNOT
WifiBuilt in 2.4G/5.8G WiFi Support IEEE 802.1.1b/g/n/ac
bt4.0
IRExit IR for 38KHz,Infra Remote control
Rear Panel
ANT IN ( EC-type IEC169-2 Female)
LNB IN (Frequency Range950MHz to 2150MHz)
HD OUT(HD2.1 , 8Kx4K@24 max resolution output )
1*USB2.0+1*USB3.0 HOST
1*TF CARD
1*SPDIF
1*RJ45
1*CA Card
Power (DC 12V/1.5A)
DVB-S/S2 specificati-ons
System standardETS 302 307
Frequency Range950~2150MHz for DVB-S/S2/S2X baseband demodulator
LNB Power and Polarization"DiSEqC1.0/1.1/1.2/USALS Motor fully support,
Symbol Rates"DVB-S QPSK,DVB-S2 QPSK/8PSK/16APSK/32APSK,
DVB-S2X QPSK/8PSK/16APSK/32APSK/64APSK"
DVB-T/T2 specificati-ons
System standardETSIEN 302 755
Frequency RangeVHF: 174~230mhz, UHF: 470~862mhz for DVB-T/T2
DemodulationCOFDM,16QAM,64QAM,256QAM
Bandwidth model6MHZ,7MHZ and 8MHZ
CountryItaly, Poland, Russia, Spanish, Sweden, United Kingdom, Germany,Greek, Slovenia, Argentina,
Australia, Denmark, Finland, France, England, Brazil, Chile, Peru, Colombia, India, Georgia, Indonesia.
FEC Code Rate1/2, 3/5, 2/3, 3/4, 4/5, 5/6
FFT2K and 8K
Guard interval1/4, 19/256, 1/8, 19/128, 1/16, 1/32, 1/128
Input Signal level:Min -80dbm max -20dbm (64QAM,8K 1/8,7/8)
Antenna Power5V DC @ 150mA MAX
ANT. ConnectorIEC 169-2, female. Input Impedance:75 Ω
ISDB-T specificati-ons
System standardISDB-T broadcast (1, 3, 13 segment),MPEG-2/MPEG-4 AVC/H.264 HD/SD Video , DiVX
Frequency RangeVHF:177.143~213.143 MHz:UHF 473.143~803.143MHz
CountryBrazil and Japan
FFT2K/ 8K/32K
DemodulationQPSK / 16QAM / 64QAM/QPSK or DQPSK
FEC Code Rate1/ 2, 2/3, 3/4, 5/6, 7/8 Automatic
Guard interval 1/4,1/8,1/16,1/32
DVB-Cable specificati-ons
Frequency Range50--858MHz For DVB-Cable (J.83A/B/C)
Demodulation16QAM,32QAM,64QAM,128QAM,256QAM
FEC Code Rate1/2 , 2/3 , 3/4 , 5/6 , 6/7 or 7/8
Input Signal levelMin -80dbm max -20dbm
Country (ATSC-C)U.S.ATSC Cable STD/U.S.ATSC Cable IRC/U.S.ATSC Cable HRC for ATSC-C
CE and RoHS approved
