Summarization
DMX Decoer adopts the advanced micro control unit, it receives standard DMX-512 digital control signal and
transformed it into PWM signal for driving LED;You could connect DMX module with DMX digital console to
achieve dimming or various changes in procedures.
Technical Parameters
Working temperature: -20-60 ℃
Supply voltage: DC12～24V
Output: 4 channel
External dimension: L165*W65*H40（mm）
Packing size: L185*W85*H60（mm）
Net weight: 310g
Gross weight: 389.5g
Static power consumption: <1W
Output current: each channel 4A
Output power: 12V:<192W, 24V:<384W
The controller output frequency: 980 Hz
Package Content:
1 Piece of LED Controller
1 Piece of User's manual
CE and RoHS approved
Shipping & Delivery
Great Choice for Green Life, CE and RoHS Approved
Quick Shipping & Online Tracking
Mostly your order will be shipped around 1 to 2 business days after payment received. If you need your order urgently,
Pls do contact us right after or before you placed orders. Pls Email to service@vozop.com
vozop.com is very easy to use, we will always provide the online tracking number to you.
The shipping fee is base on the weight of the products. You would easily choose the shipping
method (DHL/Fedex/UPS/TNT/USPS/China Air Post/Economic shipping) when you check out.
We have been in LED business for 10 years, all the products will be well packed and protected to
make sure our customer will quickly receive all the products at great condition. We weekly ship hundreds
of parcels to USA, UK, France, Germany, Italy, Switzerland, Spain, Canada, Sweden, Australia and other countries.
For customized LED Products or further assistance, Please feel free to contact our service team at service@vozop.com
